EL-280X24-0604-L128-TN
EL-280X24-0604-L128-TN
EL-280X24-0604-L128-TN
Previous Next
Click for view
EL-280X24-0604-L128-TN
Stock Code: A001049
Constant Color , MacAdams Step 3 Homogeneous illumination
PCB Materiel Aluminum 1.6 mm, Optional Selection
Substrate : ALU/FR4/CEM1/CEM3
PCB Thickness : 1.0/1.6 mm
Copper Weight : 35Um/70Um
Surface Treatment : HASL/OSP
Thermal Conductivity : 1W/1.2W/1.5W/2W
Breakdown voltage : 2000V
  • UL
  • RoHS
  • ESD
  • ENERGY
Module Code EL-280X24-0604-L128-TN
PCB Material ALU/FR4/CEM1/CEM3
Serial 6 Operating Temperature(°C) -40 ~ +85
Parallel 4 Storage Temperature(°C) -40 ~ +85
LED Quantity 48 Thermal Conductivity(W/m-k) 1W/mk

LED L128-4080SA35A00A1
Correlated Color Temperature (CCT) 2700K
Color Rendering Index (CRI) 80
Module Operating Current (mA) 250 350 500
Module Operating Voltage (V) 16,50 16,80 17,16
Module Light Output (lm) 742 1021 1427
Module Power (W) 4,13 5,88 8,58
Module Efficiency (lm/W) 179,9 173,6 166,3

LED L128-4080SA35A00A1
Correlated Color Temperature (CCT) 6500K
Color Rendering Index (CRI) 80
Module Operating Current (mA) 250 350 500
Module Operating Voltage (V) 16,50 16,80 17,16
Module Light Output (lm) 787 1081 1505
Module Power (W) 4,13 5,88 8,58
Module Efficiency (lm/W) 190,8 183,8 175,4
