EL-442X20-2103-L128
Stock Code: A001054
Constant Color , MacAdams Step 3 Homogeneous illumination
PCB Materiel Aluminum 1.6 mm, Optional Selection
Substrate : ALU/FR4/CEM1/CEM3
PCB Thickness : 1.0/1.6 mm
Copper Weight : 35Um/70Um
Surface Treatment : HASL/OSP
Thermal Conductivity : 1W/1.2W/1.5W/2W
Breakdown voltage : 2000V
  • UL
  • RoHS
  • ESD
  • ENERGY
Module Code EL-442X20-2103-L128
PCB Material ALU/FR4/CEM1/CEM3
Serial 21 Operating Temperature(°C) -40 ~ +85
Parallel 3 Storage Temperature(°C) -40 ~ +85
LED Quantity 63 Thermal Conductivity(W/m-k) 1W/mk

LED L128-4080SA35A00A1
Correlated Color Temperature (CCT) 4000K
Color Rendering Index (CRI) 80
Module Operating Current (mA) 250 350 500
Module Operating Voltage (V) 58,59 58,85 61,53
Module Light Output (lm) 2752 3736 5137
Module Power (W) 14,65 20,60 30,77
Module Efficiency (lm/W) 187,9 181,4 167,0
