EC-R20-0101-LH35-12V
Stock Code: A001073
Constant Color , MacAdams Step 3 Homogeneous illumination
PCB Materiel Aluminum 1.6 mm, Optional Selection
Substrate : ALU/FR4/CEM1/CEM3
PCB Thickness : 1.0/1.6 mm
Copper Weight : 35Um/70Um
Surface Treatment : HASL/OSP
Thermal Conductivity : 1W/1.2W/1.5W/2W
Breakdown voltage : 2000V
Module Code EC-R20-0101-LH35-12V
PCB Material ALU/FR4
Serial 1 Operating Temperature(°C) -40 ~ +85
Parallel 1 Storage Temperature(°C) -40 ~ +85
LED Quantity 1 Thermal Conductivity(W/m-k) 1W/mk

LED L1HX-4070200000000
Correlated Color Temperature (CCT) 4000K
Color Rendering Index (CRI) 70
Module Operating Current (mA) 500 700 1000
Module Operating Voltage (V) 12,00 12,00 12,00
Module Light Output (lm) 272 362 484
Module Power (W) 6,00 8,40 12,00
Module Efficiency (lm/W) 45,3 43,1 40,3
