ELCEM61L/M/H
EMERGENCY PACKS
Automatic shutdown of output if LED Ioad is out of range
Deep discharge protection
Short-circuit-proof battery connection
Open-circuit-proof
Polarity reversal protection for battery
1-3h rated duration
Self Test Emergency System
Rated supply voltage 220~240VAC
5-year guarantee (battery 3-year guarantee)
For LED module with a forward voltage of 20-90/60-250/240-430VDC
Constant voltage output
LiFePO4 with longer life
IP65 ingress protection suitable for indoor and outdoor application
Independent Emergency converter
Applications
Get Offer
Information
Part Code
Input Voltage
Output Power
Lumen Output (O/C)
Charge Duration
Duration
Battery
Function
ELCEM61L-5W-3H
220-240V
5W
10VDC-90VDC
24H
3H
3.2V 6000mAh LiFePO4
BS
ST
ELCEM61L-10W-3H
220-240V
10W
20VDC-90VDC
24H
3H
6.4V 6000mAhLiFePO4
ELCEM61M-5W-3H
220-240V
5W
60VDC-250VDC
24H
3H
3.2V 6000mAh LiFePO4
ELCEM61M-10W-3H
220-240V
10W
60VDC-250VDC
24H
3H
6.4V 6000mAh LiFePO4
ELCEM61H-5W-3H
220-240V
5W
240VDC-430VDC
24H
3H
3.2V 6000mAh LiFePO4
ELCEM61H-10W-3H
220-240V
10W
240VDC-430VDC
24H
3H
6.4V 6000mAh LiFePO4
