ELCEM70L/H - EMERGENCY LIGHTING KITS

Previous Next

ELCEM70L/H

EMERGENCY PACKS

Automatic shutdown of output if LED Ioad is out of range
Deep discharge protection
Short-circuit-proof battery connection
Open-circuit-proof
Polarity reversal protection for battery
EEC70L is SELV output voltage
1-3h rated duration
Self Test Emergency System
Rated supply voltage 220~240VAC
5-year guarantee (battery 3-year guarantee)
For LED module with a forward voltage of 20-90VDC 60-160VDC
Constant power output,output current self-adjustable
LiFePO4 with longer life
Build-in Emergency converter

Applications

Get Offer

Part Code	Input Voltage	Output Power	Lumen Output (O/C)	Charge Duration	Duration	Battery	Function
ELCEM70L-1.2W-3H	220-240V	1.2W	20VDC-90VDC	24H	3H	3.2V 1500mAh LiFePO4	BS ST
ELCEM70L-1.5W-2/3H	220-240V	1.5W	20VDC-90VDC	16/24H	2/3H	3.2V 1500/2000mAh LiFePO4
ELCEM70L-2.5W-1/2/3H	220-240V	2.5W	20VDC-90VDC	16/24H	1/2/3H	3.2V 1500/2000/3000mAh LiFePO4
ELCEM70L-3W-1/2/3H	220-240V	3W	20VDC-90VDC	16/24H	1/2/3H	3.2V 1500/3000/4000mAh LiFePO4
ELCEM08H-2.5W-3H	220-240V	1.2W	60VDC-160VDC	24H	3H	3.2V 1500mAh LiFePO4
ELCEM70H-1.5W-2/3H	220-240V	1.5W	60VDC-160VDC	16/24H	2/3H	3.2V 1500/2000mAh LiFePO4
ELCEM70H-2.5W-1/2/3H	220-240V	2.5W	60VDC-160VDC	16/24H	1/2/3H	3.2V 1500/2000/3000mAh LiFePO4
ELCEM70H-3W-1/2/3H	220-240V	3W	60VDC-160VDC	16/24H	1/2/3H	3.2V 1500/3000/4000mAh LiFePO4
