ELCEM100(L/M/H) - EMERGENCY LIGHTING KITS

Previous Next

ELCEM100(L/M/H)

EMERGENCY PACKS

Automatic shutdown of output if LED Ioad is out of range
Deep discharge protection
Short-circuit-proof battery connection
Open-circuit-proof
Polarity reversal protection for battery
EEC100L is SELV output voltage
1-3h rated duration
Self Test Emergency System
Rated supply voltage 220~240VAC
5-year guarantee (battery 3-year guarantee)
For LED module with a forward voltage of 10-90/20-90/60-250/240-430VDC
Constant power output,output current self-adjustable
LiFePO4 with longer life
Build-in Emergency converter
Can be either used build-in or independent withclip-onstrain-relief

Applications

Get Offer

Part Code	Input Voltage	Output Power	Lumen Output (O/C)	Charge Duration	Duration	Battery	Function
ELCEM100L-2.5W-1H	220-240V	2.5W	10VDC-90VDC	16H	1H	3.2V 1500mAh LiFePO4	BS ST
ELCEM100L-2.5W-2H	220-240V	2.5W	10VDC-90VDC	16H	2H	3.2V 2000mAh LiFePO4
ELCEM100L-2.5W-3H	220-240V	2.5W	10VDC-90VDC	16H	3H	3.2V 3000mAh LiFePO4
ELCEM100L-5W-1H	220-240V	5W	10VDC-90VDC	16H	1H	3.2V 3000mAh LiFePO4
ELCEM100L-5W-2H	220-240V	5W	10VDC-90VDC	16H	2H	3.2V 4000mAh LiFePO4
ELCEM100L-5W-3H	220-240V	5W	10VDC-90VDC	16H	3H	3.2V 6000mAh LiFePO4
ELCEM100L-7W-2H	220-240V	7W	20VDC-90VDC	24H	2H	6.4V 3000mAh LiFePO4
ELCEM100L-10W-1H	220-240V	10W	20VDC-90VDC	24H	1H	6.4V 3000mAh LiFePO4
ELCEM100M-2.5W-1H	220-240V	2.5W	60VDC-250VDC	16H	1H	3.2V 1500mAh LiFePO4
ELCEM100M-2.5W-2H	220-240V	2.5W	60VDC-250VDC	16H	2H	3.2V 3000mAh LiFePO4
ELCEM100M-2.5W-3H	220-240V	2.5W	60VDC-250VDC	16H	3H	3.2V 3000mAh LiFePO4
ELCEM100M-5W-1H	220-240V	5W	60VDC-250VDC	16H	1H	3.2V 3000mAh LiFePO4
ELCEM100M-5W-2H	220-240V	5W	60VDC-250VDC	16H	2H	3.2V 4000mAh LiFePO4
ELCEM100M-5W-3H	220-240V	5W	60VDC-250VDC	16H	3H	3.2V 6000mAh LiFePO4
ELCEM100M-7W-2H	220-240V	7W	60VDC-250VDC	24H	2H	6.4V 3000mAh LiFePO4
ELCEM100M-10W-1H	220-240V	10W	60VDC-250VDC	24H	1H	6.4V 3000mAh LiFePO4
ELCEM100H-2.5W-1H	220-240V	2.5W	240VDC-430VDC	16H	1H	3.2V 1500mAh LiFePO4
ELCEM100H-2.5W-2H	220-240V	2.5W	240VDC-430VDC	16H	2H	3.2V 2000mAh LiFePO4
ELCEM100H-2.5W-3H	220-240V	2.5W	240VDC-430VDC	16H	3H	3.2V 3000mAh LiFePO4
ELCEM100H-5W-1H	220-240V	5W	240VDC-430VDC	16H	1H	3.2V 3000mAh LiFePO4
ELCEM100H-5W-2H	220-240V	5W	240VDC-430VDC	16H	2H	3.2V 4000mAh LiFePO4
ELCEM100H-5W-3H	220-240V	5W	240VDC-430VDC	16H	3H	3.2V 6000mAh LiFePO4
ELCEM100H-7W-2H	220-240V	7W	240VDC-430VDC	24H	2H	6.4V 3000mAh LiFePO4
ELCEM100H-10W-1H	220-240V	10W	240VDC-430VDC	24H	1H	6.4V 3000mAh LiFePO4
